Corazon Pipes and Tubes is a reputable manufacturer and supplier located in Manila, Philippines, focusing on high-quality AISI 4140 pipes designed for tough industrial applications. With a strong dedication to precision engineering, durability, and customer satisfaction, the company delivers products that adhere to international standards and perform reliably under intense stress and pressure. Catering to sectors like construction, manufacturing, energy, and automotive, Corazon Pipes and Tubes has built a reputation for consistent quality, timely deliveries, and expert technical support, making it a go-to partner for clients in search of trustworthy alloy-steel piping solutions in the region.
AISI 4140 pipes are crafted from a chromium-molybdenum alloy steel, renowned for its remarkable strength and toughness. Their typical composition includes carbon (0.38–0.43%), chromium (0.80–1.10%), molybdenum (0.15–0.25%), manganese (0.75–1.00%), along with trace amounts of silicon and sulfur. These elements work together to provide high hardenability, tensile strength, and fatigue resistance. The pipes boast excellent mechanical performance, featuring high yield strength, wear resistance, and the capability to endure elevated temperatures, making them perfect for heavy-duty and high-pressure settings.
Specification : ASTM B861, B338, B388, B862 / ASME SB861, SB338, SB388, SB862
Pipe Range : ½”NB to 24”NB / SCH 10 – SCH XXS
Tubes Range: 1mm OD to 254mm OD / Thickness 0.1 to 20mm.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
| Al | Fe | O | Ti | V |
|---|---|---|---|---|
| max | max | max | max | max |
| 6 | 0.25 | 0.2 | 90 | 4 |
| Hardness, Brinell | 334 | 334 | Estimated from Rockwell C. |
|---|---|---|---|
| Hardness, Knoop | 363 | 363 | Estimated from Rockwell C. |
| Hardness, Rockwell C | 36 | 36 | |
| Hardness, Vickers | 349 | 349 | Estimated from Rockwell C. |
| Tensile Strength, Ultimate | 950 MPa | 138000 psi | |
| Tensile Strength, Yield | 880 MPa | 128000 psi | |
| Elongation at Break | 14 % | 14 % | |
| Reduction of Area | 36 % | 36 % | |
| Modulus of Elasticity | 113.8 GPa | 16500 ksi | |
| Compressive Yield Strength | 970 MPa | 141000 psi | |
| Notched Tensile Strength | 1450 MPa | 210000 psi | Kt (stress concentration factor) = 6.7 |
| Ultimate Bearing Strength | 1860 MPa | 270000 psi | e/D = 2 |
| Bearing Yield Strength | 1480 MPa | 215000 psi | e/D = 2 |
| Poisson’s Ratio | 0.342 | 0.342 | |
| Charpy Impact | 17 J | 12.5 ft-lb | V-notch |
| Fatigue Strength | 240 MPa | 34800 psi | at 1E+7 cycles. Kt (stress concentration factor) = 3.3 |
| Fatigue Strength | 510 MPa | 74000 psi | Unnotched 10,000,000 Cycles |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Gr 5 Tubing from Corazon Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Corazon Pipes and Tubes, a leading supplier of Titanium Gr 5 Tubing in Manila, Philippines, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Corazon Pipes and Tubes, we provide custom sizes of Titanium Gr 5 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
AISI 4140 pipes find extensive use in industries that demand durable, high-performance materials. Their outstanding mechanical properties make them ideal for producing shafts, axles, drill collars, hydraulic components, and various machinery parts. In the automotive industry, they are utilized for gears, crankshafts, and suspension components. The oil and gas sector appreciates AISI 4140 pipes for their ability to withstand high pressure and harsh conditions, making them perfect for drilling tools and downhole equipment. Additionally, they are employed in construction, heavy equipment manufacturing, power generation, and industrial tooling where strength and reliability are crucial.
