Home > Stainless Steel > Stainless Steel ERW Pipes
Nestled in the industrial heart of Manila, Corazon Pipes and Tubes has built its reputation on a foundation of quality and reliability. As a dedicated manufacturer and supplier, we specialize in the production of Stainless Steel Electric Resistance Welded (ERW) Pipes, serving the diverse needs of the Philippine market. Our commitment extends beyond manufacturing; we are your trusted partner, ensuring that every pipe meets rigorous standards for performance and durability. When you choose Corazon, you are selecting excellence forged from years of expertise and a genuine dedication to customer success.
Our Stainless Steel ERW Pipes are crafted from premium alloys like 304 and 316, known for their excellent composition that naturally resists corrosion. This material choice directly translates into superior mechanical properties, including impressive tensile strength and the ability to withstand high internal pressures. The unique electric resistance welding process creates a seamless, robust bond along the pipe’s length, enhancing its structural integrity. This combination of material excellence and precise manufacturing ensures a product that performs reliably under demanding conditions, project after project.
| Standard Specification | ASTM A312, A270, A249, A269, A268, A358, A213 |
| ANSI / ASME Specification | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Shapes and Types we produce | Hex, Hydraulic, Square, Round, Honed, Rectangle |
| Manufacturing Type | Fabricated, 100% X Ray Welded, ERW (Electric Resistance Welded), CDW, Welded |
| Pipe End Forming | Plain One End, Beveled One End, Bevel large end, Bevel one end, Bevel both ends, Beveled end, Bevel small end, Plain Both Ends, Treaded Both Ends, Treaded On End |
| Various TDC Types | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Material Surface Finish | 2B, No.4, No.1, No.8 Mirror Finish or custom Finish as per customer Requirements |
| ASME B36.10 Pipe Schedules | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Available Value Added Services | Color Coding, Cutting, Threading, Grooving, Export Documentation, MTR’s Available, Polishing, Material testing, Beveling, Destructive, Threading, Export Packaging, Destructive, Machining, Non Customer Tagging/ Marking, Ultrasonic Testing |
| Marking |
|
| Grades |
|
| Grade | Elastic Modulus (GPa) | Electrical Resistivity (nΩ.m) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Density (kg/m3) | Specific Heat 0-100°C (J/kg.K) | Thermal Conductivity (W/m.K) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| SS ERW Pipe | 193 | 720 | 17.2 | 17.8 | 18.4 | 8000 | 500 | 16.2 | 21.5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel ERW Pipes from Corazon Pipes and Tubes ensures high-quality, corrosion-resistant pipes with excellent durability and strength. We provide reliable performance in demanding environments, and our electric resistance Welded (ERW) process guarantees superior precision and consistency in manufacturing.
Corazon Pipes and Tubes, one of the largest suppliers of Stainless Steel ERW Pipes in Manila, Philippines, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Nominal size in Inch | Wall thickness in Inch | Outside diameter in mm | Wall thickness in mm | Outside diameter in Inch | Weight [Kg/M] | Weight [lb/ft] |
|---|---|---|---|---|---|---|
| 1/2 Inch | 0.065 | 21.3 mm | 1.65 | 0.840 | 0.80 | 0.54 |
| 3/4 Inch | 0.065 | 26.7 mm | 1.65 | 1.050 | 1.03 | 0.69 |
| 1 Inch | 0.065 | 33.4 mm | 1.65 | 1.315 | 1.30 | 0.87 |
| 1 1/4 Inch | 0.065 | 42.2 mm | 1.65 | 1.660 | 1.66 | 1.12 |
| 1 1/2 Inch | 0.065 | 48.3 mm | 1.65 | 1.900 | 1.91 | 1.28 |
| 2 Inch | 0.065 | 60.3 mm | 1.65 | 2.375 | 2.40 | 1.61 |
| 2 1/2 Inch | 0.083 | 73.0 mm | 2.11 | 2.875 | 3.71 | 2.49 |
| 3 Inch | 0.083 | 88.9 mm | 2.11 | 3.500 | 4.54 | 3.05 |
| 3 1/2 Inch | 0.083 | 101.6 mm | 2.11 | 4.000 | 5.21 | 3.50 |
| 4 Inch | 0.083 | 114.3 mm | 2.11 | 4.500 | 5.88 | 3.95 |
| 5 Inch | 0.109 | 141.3 mm | 2.77 | 5.563 | 9.52 | 6.40 |
| 6 Inch | 0.109 | 168.3 mm | 2.77 | 6.625 | 11.38 | 7.65 |
| 8 Inch | 0.109 | 219.1 mm | 2.77 | 8.625 | 14.87 | 9.99 |
| 10 Inch | 0.134 | 273.1 mm | 3.4 | 10.750 | 22.76 | 15.29 |
| 12 Inch | 0.156 | 323.9 mm | 3.96 | 12.750 | 31.44 | 21.13 |
| 14 Inch | 0.156 | 355.6 mm | 3.96 | 14.000 | 34.56 | 23.22 |
| 16 Inch | 0.165 | 406.4 mm | 4.19 | 16.000 | 41.83 | 28.11 |
| 18 Inch | 0.165 | 457.0 mm | 4.19 | 18.000 | 47.09 | 31.64 |
| 20 Inch | 0.188 | 508.0 mm | 4.78 | 20.000 | 59.70 | 40.12 |
| 22 Inch | 0.188 | 559.0 mm | 4.78 | 22.000 | 65.75 | 44.18 |
| 24 Inch | 0.218 | 610.0 mm | 5.54 | 24.000 | 83.11 | 55.85 |
| 30 Inch | 0.250 | 762.0 mm | 6.35 | 30.000 | 119.09 | 80.02 |
Yes, we offer custom sizes for Stainless Steel ERW Pipes to meet your specific requirements. Our team at Corazon Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@corazonpipes.com.
Stainless Steel ERW Pipes find extensive use in industries that demand durability, corrosion resistance, and cost-effective solutions. They are perfect for transporting water, oil, gas, and other fluids in low-to-medium pressure pipelines. Common applications include chemical and petrochemical plants, food and beverage processing, pharmaceutical sectors, and water treatment systems. In the construction realm, ERW pipes are utilized for structural purposes, handrails, and architectural designs. Their smooth surface, ease of welding, and precise dimensions make them a go-to choice for various applications, ensuring they meet the diverse needs of different industries.
