- Manila, Philippines
Corazon Pipes and Tubes is a reputable manufacturer and supplier of Titanium Boiler Tubing located in Manila, Philippines. They specialize in high-performance tubing that can withstand extreme temperatures and corrosive environments found in boilers. Their titanium boiler tubes are crafted with meticulous attention to detail, ensuring precise tolerances, consistent wall thickness, and outstanding surface quality for long-lasting reliability and effective heat transfer. Renowned for their remarkable corrosion resistance, lightweight strength, and durability, these tubes are perfect for high-pressure and high-temperature boiler systems. Corazon Pipes and Tubes delivers tubing that adheres to strict international standards, catering to power plants, chemical industries, marine sectors, and industrial heating systems that demand top-notch performance and longevity.
Titanium Boiler Tubing is made from commercially pure titanium or titanium alloys, with carefully controlled levels of oxygen, nitrogen, carbon, hydrogen, and iron. This specific composition grants exceptional corrosion resistance, particularly in hot, high-pressure, and chemically aggressive settings. Mechanically, these tubes boast high tensile and yield strength, impressive fatigue resistance, excellent thermal stability, and a low density. They perform reliably under extreme boiler temperatures and pressures while ensuring efficient heat transfer. These characteristics make titanium boiler tubes the go-to choice for systems that require reliability, lightweight strength, and an extended service life.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance | Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or beveled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing | A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Boiler Tubing from Corazon Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Corazon Pipes and Tubes, a leading supplier of Titanium Boiler Tubing in Manila, Philippines, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Corazon Pipes and Tubes, we provide custom sizes of Titanium Boiler Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@corazonpipes.com.
Titanium Boiler Tubing finds extensive application in industries where high temperatures, pressure, and corrosion create challenging operating conditions. Power generation plants utilize it in boilers, heat exchangers, condensers, and superheaters to achieve efficient heat transfer and long-lasting durability. In the chemical processing sector, it effectively manages corrosive fluids and high-temperature steam systems. The marine and desalination industries depend on titanium boiler tubes for seawater cooling and brine heating, ensuring optimal performance in demanding environments.
