Stainless Steel 321H Pipes

Home > Stainless Steel > Stainless Steel 321H Pipes

Stainless Steel 321H Pipes Manufacturer, Supplier and Exporter in Manila, Philippines

Based in the vibrant industrial landscape of Manila, Corazon Pipes and Tubes has built a reputation for reliability and expertise in the metal supply industry. We specialize in providing high-performance materials engineered for demanding environments, with our Stainless Steel 321H pipes standing as a prime example of this commitment. We understand that our clients need more than just a product; they need a dependable partner offering solutions that ensure longevity, safety, and operational efficiency in their critical projects across the Philippines and beyond.

321H Stainless Steel Pipes Exporter in Philippines, SS UNS S32109 Pipes Exporter in Cebu City, 321H Stainless Steel Pipe Manufacturer in West Manila, SUS 321H Pipes Price List in Philippines, ASTM A312 Stainless Steel 321H Pipe Supplier in Manila,Stainless Steel 1.4878 Pipes in Cebu City

The strength of Stainless Steel 321H lies in its carefully balanced composition, which includes chromium, nickel, and a stabilising titanium addition that prevents harmful carbide precipitation. This specific chemistry grants the material outstanding resistance to intergranular corrosion, especially after exposure to high temperatures. Furthermore, the “H” designation indicates a higher carbon content, which directly translates to superior elevated temperature strength, allowing these pipes to maintain their structural integrity and resist creep under sustained stress in high-heat applications.

Stainless Steel 321H Pipes Specification

Pipe Standard	ASTM A312 ASME SA312 / ASTM A358 ASME SA358
Pipe Dimension	ANSI/ASME B36.19M, ANSI/ASME B36.10M
Pipe Sizes	1 / 2″ NB – 24″ NB
Pipe Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Steel Pipe Manufacturing Process	Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Stainless Steel Pipe Shapes	Hydraulic, Round, Rectangle, Square, Hex, Honed
Stainless Steel Pipe Schedule	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Pipe Ends	Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Value Added Services	Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing

Stainless Steel 321H Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	N	Ni	Ti
SS 321H	0.04 – 0.10	2.0 max	1.0 max	0.045 max	0.030 max	17.00 – 19.00	0.10 max	9.00 – 12.00	4(C+N) – 0.70 max

SS 321H Pipes Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1457 °C (2650 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASME SA 312 TP321H Pipes Manila,Stainless Steel 321H Pipes Supplier in Philippines, 321H Stainless Steel Pipes Exporter in West Manila, SS UNS S32109 Pipes Supplier in Manila, SS 321H Schedule 20 Pipe Exporter in Cebu City

Why Choose Stainless Steel 321H Pipes from Corazon Pipes and Tubes?

Choosing Stainless Steel 321H Pipes from Corazon Pipes and Tubes offers corrosion resistance and excellent durability, ideal for harsh environments. Their pipes are precisely engineered for durability and reliability, conforming to stringent industry standards. Corazon offers solutions tailored to suit specific business requirements, backed by exceptional customer service. Furthermore, their commitment to quality ensures longevity and performance, making them a reliable choice for a variety of applications. Trust Corazon’s expertise in providing quality stainless steel for your needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 321H Pipes Supplier in Manila, Philippines

Corazon Pipes and Tubes, one of the largest suppliers of Stainless Steel 321H Pipes in Manila, Philippines, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 321H Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

SS 321H Schedule 40 Pipe Price List in Manila, Stainless Steel S32109 Pipes Supplier in Cebu City, SS 321H Pipes Supplier in Philippines, ASTM A312 Stainless Steel 321H Pipe Exporter in West Manila, AISI 321H Pipes Exporter in Manila,1 inch SS 321H Pipe Price in Puerto Princesa, SS 321H Pipe Weight Chart, SS 321H Schedule 20 Pipe Thickness, 321H Austenitic Stainless Steel Pipe Supplier in Philippines

Types of Stainless Steel 321H Pipes

Are Custom Sizes Available for Stainless Steel 321H Pipes?

Yes, we offer custom sizes for Stainless Steel 321H Pipes to meet your specific requirements. Our team at Corazon Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@corazonpipes.com.

SS UNS S32109 Pipes Exporter in Puerto Princesa, SUS 321H Pipes Supplier in Cebu City, 321H SS Pipes Manufacturer in West Manila, 321H Austenitic Stainless Steel Pipe Dealer in Manila, Stainless Steel S32109 Pipes Manufacturer in Manila,SS 321H Pipe Supplier in Philippines

Stainless Steel 321H Pipes find extensive application in high-temperature services including heat exchangers, boiler tubes, furnace components, superheater tubes, and chemical processing equipment. They can also be applied in oil refineries, thermal oxidizers, and exhaust systems where long-time exposure to high temperature is anticipated. The increased carbon content enhances high-temperature strength, thus making these pipes highly suitable for pressure-containing systems under conditions of extreme heat. Stainless Steel 321H offers a durable and dependable solution for applications where resistance to scaling, oxidation, and thermal fatigue is demanded.
