Home > Stainless Steel >Stainless Steel 317 and 317L EFW Pipes
From the heart of Manila’s industrial landscape, Corazon Pipes and Tubes has built a reputation for supplying robust and reliable materials. We take pride in being your trusted source for Stainless Steel 317/317L EFW Pipes, engineered to meet the highest standards for demanding environments. Our commitment lies in delivering not just a product, but a dependable solution that supports the integrity and longevity of your critical projects, backed by our deep understanding of the local market’s unique needs and challenges.
The strength of 317/317L stainless steel lies in its advanced composition, which includes higher levels of molybdenum, chromium, and nickel compared to standard 316 grades. This specific blend gives these pipes an exceptional ability to resist a wide range of corrosive chemicals, particularly chlorides that can cause pitting. Mechanically, they offer excellent tensile strength and good ductility, allowing them to perform reliably under high-stress conditions and making them a fundamentally tougher choice for challenging applications.
| Specification | ASTM A358 / ASME SA358 |
| Specification | A / SA358 CLASS 1, A / SA358 CLASS 2, A / SA358 CLASS 3, A / SA358 CLASS 4, A / SA358 CLASS 5 |
| Grades | 304, 304L, 304H, 309S, 310S, 316, 316L, 316H, 317L, 321, 321H, 347, 347H, 904L ETC. |
| Type | EFW, ELECTRIC FUSION WELDED |
| Outer Diameter Size | Electric Fusion Welded / ERW- 8″ NB To 110″ NB (Nominal Bore Size) |
| Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
| Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
| Ends | Plain Ends / Beveled Ends |
| Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered |
| Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| STANDARD | UNS | WERKSTOFF NR. | EN | JIS |
| SS 317 | S31700 | 1.4449 | – | SUS 317 |
| SS 317L | S31703 | 1.4438 | X2CrNiMo18-15-4 | SUS 31 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| Psi – 75000, MPa – 515 | Psi – 30000, MPa – 205 | 35 % | 95 | 217 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 317 and 317L EFW Pipes from Corazon Pipes and Tubes guarantees excellent corrosion resistance, high strength, and durability. Designed for diverse industrial applications, it delivers reliable performance in tough environments while maintaining competitive pricing for cost-effective solutions.
| NPS Designator | Outside Diameter | Nominal Wall Thickness | ||||||||
| in. | mm | Schedule 5SA | Schedule 10SA | Schedule 40SA | Schedule 80SA | |||||
| in. | mm | in. | mm | in. | mm | in. | mm | |||
| 8 | 8.625 | 219.08 | 0.109 | 2.77 | 0.148 | 3.76 | 0.322 | 8.18 | 0.500 | 12.70 |
| 10 | 10.750 | 273.05 | 0.134 | 3.40 | 0.165 | 4.19 | 0.365 | 9.27 | 0.500B | 12.70B |
| 12 | 12.750 | 323.85 | 0.156 | 3.96 | 0.180 | 4.57 | 0.375B | 9.52B | 0.500B | 12.70B |
| 14 | 14.000 | 355.60 | 0.156 | 3.96 | 0.188B | 4.78B | … | … | … | … |
| 16 | 16.000 | 406.40 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 18 | 18.000 | 457.20 | 0.165 | 4.19 | 0.188B | 4.78B | … | … | … | … |
| 20 | 20.000 | 508.00 | 0.188 | 4.78 | 0.188B | 4.78B | … | … | … | … |
| 22 | 22.000 | 558.80 | 0.188 | 4.78 | 0.218B | 5.54B | … | … | … | … |
| 24 | 24.000 | 609.60 | 0.218 | 5.54 | 0.250 | 6.35 | … | … | … | … |
| 30 | 30.000 | 762.00 | 0.250 | 6.35 | 0.312 | 7.92 | … | … | … | … |
|
Physical Properties (Room Temperature) |
||
|
Specific Heat (0-100°C) |
500 |
J.kg-1.°K-1 |
|
Thermal Conductivity |
14.6 |
W.m -1.°K-1 |
|
Thermal Expansion |
16.5 |
mm/m/°C |
|
Modulus Elasticity |
193 |
GPa |
|
Electrical Resistivity |
7.4 |
μohm/cm |
|
Density |
7.99 |
g/cm |
We offer custom sizes for Stainless Steel 317 and 317L EFW Pipes to meet your specific needs. Our dedicated team at Corazon Pipes and Tubes provides tailored solutions for all your piping and tubing requirements. For more information, contact us at sales@corazonpipes.com.
**Stainless Steel 317 and 317L EFW Pipes** are widely utilized in chemical processing, petrochemical facilities, and marine settings due to their excellent corrosion resistance. They are particularly suited for managing acids, solvents, and other aggressive fluids. In the power generation sector, you’ll find them in boilers, superheaters, and pipelines. The food, beverage, and pharmaceutical industries also rely on them for hygienic, contamination-free processing systems. Moreover, they are commonly used in oil and gas pipelines, offshore applications, and more.
